GXS90
Hydraulic Hammer
Blows Per Minute
450-900
-
BPM
Impact Energy
1500
-
Ft-Lbs.
Operating Weight
1500/676
-
Lbs/KG.
Explore GXS90
About the Gorilla®GXS90
Our customers tell us the GXS90 is the most power you can put on an 8-ton machine-and we believe them! Designed for big boy backhoes and mini excavators from 8-12 tons, the GXS90 brings 1,500 ft lbs. of rock shattering impact power to your jobsite. This high-performance hydraulic hammer is engineered for demanding excavation and demolition environments such as rockbreaking, heavy concrete removal, trenching, and foundation work. Of course, baked in is our low maintenance design with two moving parts that gives you the durability contractors expect from a full-size Gorilla hammer.
GXS90 Full Specifications
-
Impact Energy 1500 ft.lbs.
-
Operating Weight 1500/676 lbs/kg.
-
Blows per Minute 450-900 bpm
-
Tool Diameter 3.4/85 in./mm.
-
Carrier Weight (Tons) 8-12 tons
-
Carrier Weight (Lbs) 17600-26400 lbs.
-
Oil Flow Rate 12-23/45-85 GPM/LPM
-
Operating Oil Pressure 1850-2100/130-150 PSI/BAR
-
Auxiliary Circuit Relief 2800/195 PSI/BAR
Have questions, need help, or want to request additional information? Contact Gorilla Hammers now!
Customers Also Viewed
Machine Fitment List
JCB 100C-1, 85Z-2, 86C-2, 90Z-2
MECALAC 10MCR, 11CX, 11CXI, 11MWR, 12MSX, 12MTX, 12MX, 12MXT, 12MXTE, 9MWR, E12, R11CXR
WACKER NEUSON 12002, 12002RD, 12002RDV, 8002, 8002RD, 8003, 8003-2, 8003RD, ET90, EZ80, G6002RD, G8003RD
LINKBELT 2650, 2650Q, 75X3, 80 SPIN ACE, 80 X3 SPIN ACE, 80X3, LS-2650, LS-2650 II, LS-2650C, LS-2650C II
CAT 272, 272C, 272D, 272D XHD, 272D XHP, 272D2, 272D2 XHP, 272D3, 272D3 XE, 307, 307.5, 307B, 307BSB, 307C, 307CL, 307CSB, 307D, 307E, 307E 2, 307SSR, 308, 308CR, 308CRVAB, 308DCR, 308DCRSB, 308E2CRSB, 308ECRSB, 309, 309CR, 309CRVAB, 310, 311, 311B, 311C, 311CLU, 311CU, 311DLRR, 311FLRR, 311FRR, 312, 312B, 312BL, 312C, 312CL, 312D, 312DL, 312E, 312L, 415, 415F2, 415F2IL, 415IL, 416, 416B, 416C, 416CIT, 416D, 416DIT, 416E, 416F, 416F2, 420, 420D, 420DIT, 420E, 420EIT, 420F, 420F2, 420F2IT, 420XE, 422, 422E, 428, 428B, 428C, 428F, 430, 430D, 430DIT, 430E, 430EIT, 430F, 430F2, 430F2IT, 430FIT, 432, 432F, 434, 436, 436 SERIES II, 436B, 436C, 446, 446B, 446D, 914, 914G, 914G2, 924, 924G, 924GZ, 924H, 924HZ, 924K, 928, 928G, 928GZ, 928HZ, 931, 931B, 931C, 935 CII, E110B, E120B, IT12, IT14, IT14G, IT14G2, IT18, IT18B, IT28, IT28B, IT28F, IT28G, M312
CASE 521F, 580, 580 SUPER, 580 SUPER E, 580 SUPER K, 580 SUPER L, 580 SUPER L SERIES 2, 580 SUPER M, 580 SUPER M SERIES 2, 580 SUPER M SERIES 3, 580 SUPER M+ SERIES 2, 580 SUPER M+ SERIES 3, 580 SUPER N, 580 SUPER N WT, 580B, 580C, 580D, 580E, 580EP, 580EV, 580F, 580K, 580L, 580L SERIES 2, 580M, 580M SERIES 2, 580M SERIES 3, 580M TURBO, 580M TURBO SERIES 2, 580N, 580N EP, 580SK, 580SN, 580SNWT, 580SV, 590 SUPER M, 590 SUPER M SERIES 2, 590 SUPER M SERIES 3, 590 SUPER M+ SERIES 3, 590 SUPER N, 680, 680B, 680C, 680E, 680G, 680H, 680K, 680L, 688, 695SR, 770EX, 770EX MAGNUM, 770EX PLUS, 780, 780B, 780C, 780D, CX80, CX85, CX85E, CX90, CX90E
JOHN DEERE 75C, 75D, 75G, 80, 80C, 80C OFFSET BOOM, 85D, 85G
KOBELCO 80CS, 80CS ACERA, 80MSR, K903, K903 II, K903 III, K903 LC II, K903A, K903B, K903C, K903P, K904, K904 II, K904 III, K904 LC II, K904A, K904B, K904BL, K904C, K904CL, K904D, K904E, K905, K905 II, K905 III, K905 LC, K905 LC II, K905A, K905A LC, K905C, K905C LC II, K905D LC, R903A, R904A, R904AL, R904B, R904BL, SK100, SK100 ACERA, SK100 I, SK100 II, SK100 III, SK100 IV, SK100 LC, SK100 LC II, SK100 LC IV, SK100 V, SK100L, SK100L III, SK100R, SK100SV, SK100SV II, SK115, SK115 LC IV, SK115DZ, SK115DZ IV, SK115DZ LC IV, SK115SR, SK115SR LC, SK115SR-1, SK115SR-1ES, SK115SRDZ, SK115SRDZ-15, SK115SRDZ-1E, SK120, SK120 ACERA SV, SK120 I, SK120 II, SK120 IV, SK120 LC, SK120 LC II, SK120 LC III, SK120 LC IV, SK120 LC V, SK120 LL, SK120 LL IV, SK120 LP, SK120 LP III, SK120 V, SK120BK, SK120L, SK120MKV, SK120S V, SK120U, SK75, SK80, SK80C, SK80CA, SK80CS, SK80CS SR, SK80CS-1E, SK80CS-2, SK80MSR, SK80MSR LC, SK80MSR-1, SK80MSR-1E, SK80MSR-2, SK80SR, SK80UR-6, SK80UR-6E, SK85, SK85CS, SK85CS-3, SK85CS-3E, SK85CS-7, SK85MSR, SK85MSR-3E, SK85MSR-7, SK85SR, SK85UR-3, SK95UR
IHI 80NX, 80NX-3, 80VX, 80VX-3, 85V-4
TEREX 860 ELITE, 860SX, 880 ELITE, 880SX, 970 ELITE, 980 ELITE, HML32, HML42, TC85, TLB840, TLB840R, TLB850, TLB890, TLB990, TW110, TW85
LIUGONG 906FG4, 908C, 908D, 908E, 909ECR
BOBCAT B750, B760, B780, E85
DAEWOO DX80R, DX85Z, S75-V
DOOSAN DL200, DL200A, DL200TC, DX80R, DX85R-3
NEW HOLLAND E115SR, E115SR-1ES, E80, E80-1ES, E80B, E80BMSR, E80MSR, E80MSR-1ES, E80SR, E85D, E90D, E95R, EC110 LC
VOLVO EC120, EC120D, EC130, EC80D, EC80D PRO, ECR88, ECR88 PLUS, ECR88B, ECR88D, ECR88D PRO
HITACHI EX100, EX100-2, EX100-3, EX100W, EX100WD, EX110, EX110-5, EX120, EX120-2, EX120-3, EX80, EX80-5, ZX120, ZX120-3, ZX75, ZX75US, ZX75US-3, ZX75US-5, ZX80, ZX80 OFFSET BOOM, ZX85, ZX85USB-3, ZX85USB-5
GEHL M100, Z80, Z80 GEN 2
GRADALL XL2200, XL2210
KATO HD308US-7, HD512LC-7, HD85V5
HYUNDAI HX85, HX85A, R80, R80-7, R80-7A, R80CR-9, R80CR-9A
KOMATSU PC100, PC100 LC, PC100 LC-1, PC100 LC-2, PC100 LC-3, PC100 LC-5, PC100 LC-6, PC100-1, PC100-2, PC100-3, PC100-4, PC100-5, PC100-5Z, PC100-6, PC100-6E, PC100-8, PC100L, PC100L-1, PC100L-2, PC100L-3, PC100N, PC100N-6, PC100SS-3, PC100U, PC100U-2, PC100U-3, PC110, PC110-1, PC110-2, PC110-7, PC110R, PC110R-1, PC110SP-6, PC118MR-8, PC120, PC120 LC, PC120 LC-3, PC120 LC-4, PC120 LC-5, PC120 LC-5L, PC120 LC-6, PC120 LC-6E, PC120 LC-6E0, PC120 LC-6L, PC120 LC-6LE, PC120 LC-7, PC120 LE, PC120-1, PC120-11, PC120-15, PC120-2, PC120-3, PC120-3K, PC120-3W, PC120-4, PC120-5, PC120-5C, PC120-5G, PC120-5K, PC120-5Z, PC120-6, PC120-6AC, PC120-6E, PC120-6E0, PC120-6J, PC120-6L, PC120-6M, PC120-6Z, PC120-6ZE, PC120-7, PC120-8, PC120B, PC120BE, PC120SC-6E, PC120SS-3, PC120UU, PC128, PC128-1, PC128-2, PC128U, PC128U-2, PC128US, PC128US LC, PC128US LC-2, PC128US-1, PC128US-10, PC128US-11, PC128US-1MB, PC128US-2, PC128US-2A, PC128US-2E0, PC128US-2E1, PC128US-2H, PC128US-2MB, PC128US-5, PC128US-6, PC128US-8, PC128UU, PC128UU-1, PC128UU-15, PC128UU-1E, PC128UU-1Y, PC128UU-2, PC128UU-2E0, PC128UU-6, PC128UU-8, PC128UUMB, PC76UU-2, PC78, PC78MR, PC78MR-1, PC78MR-2, PC78MR-5, PC78MR-6, PC78MRX-1, PC78R, PC78U, PC78US, PC78US LC, PC78US-2, PC78US-5, PC78US-6, PC78US-6N0, PC78US-8, PC78UU-10, PC80, PC80 LC-3, PC80-1, PC80-3, PC80-5, PC80MR, PC80MR-3, PC80MR-5, PC88, PC88MR, PC88MR-10, PC88MR-11, PC88MR-6, PC90, PC90-1, PC90-5, PC90-6, PC90-7, PC90R-2, PC91, PC95, PC95-1, PC95-2, PC95-5, PC95-6, PC95R, PC95R-1, PC95R-2, PC95RT
KUBOTA KX080
LIEBHERR R308, R310, R310B
MITSUBISHI MS120-2, MS120-8
SAMSUNG SE130LC, SE130LC-2, SE130LC-3, SE130LCM-2, SE130LCM-3, SE130W, SE130W-3, SE50-3
SANY SY115C, SY125C PRO, SY80U, SY85C, SY95, SY95C, SY95C PRO
YANMAR SV100, SV100-1, SV100-1A, SV100-2, SV100-2A, SV100-2B, SV100-7, SV100VCR, SV120, SV85, SV86-7, VIO80, VIO80-1, VIO80-1A, VIO80-1B, VIO80-7, VIO80-B, VIO80U, VIO82, VIO85, YB601U
TAKEUCHI TB290, TB75FR, TB80FR
XCMG XE80U
Machine not listed, or have additional questions? We’re ready to help. Contact Gorilla Hammers any time!
